SNF Series
SNF Series Product Introduction
|
MODEL |
SNF1500-22406H SNF2500-22410H SNF3500-222410H SNF6000-24812H SNF11K-24816H |
||||
|
Rated load power |
1500W |
2500W |
3500W |
6000W |
11000W |
|
parallel function |
Without parallel |
≤12 units in parallel.Parallal output 380AC |
≤6 units in parallel.Parallel output 38DAC |
||
|
MAX PV Array Power |
2000W |
3000W |
4000W |
6500W |
5500W*2=11KW |
|
MPPT input interface |
l way |
2way |
|||
|
Battery rated voltage |
24VDC |
24VDC |
24VDC |
48VDC |
48VDC |
|
Lithium battery activation |
Photovoltalc charging activation |
Mains& Photovoltalc charging activation |
|||
|
AC INPUT |
|
||||
|
Voltage |
230VAC |
||||
|
Selectable Voltage Range |
170-280VAC(for personal computers)/90-280VAC(for home appliances) |
||||
|
Frequency Range |
50Hz/60Hz(Auto detection) |
||||
|
AC OUTPUT |
|
||||
|
AC Voltage Regulation(Batt. Mode) |
230VAC±5% |
||||
|
Surge power |
3000W |
5000W |
7000W |
12000W |
22000W |
|
Transfer Time |
10ms(for personal computers)/20ms(for home appliances) |
||||
|
BATTERY &AC CHARGER |
|
||||
|
Battery Voltage |
24VDC |
24VDC |
24VDC |
48VDC |
48VDC |
|
Floating Charge Voltage |
27VDC |
27VDC |
27VDC |
54VDC |
54VDC |
|
Overcharge Protection |
31VDC |
31VDC |
31VDC |
61VDC |
61VDC |
|
Maximum charge current |
60A |
60A |
80A |
80A |
120A |
|
SOLAR CHARGER |
|
||||
|
MAX PV Array Power |
2000W |
3000W |
4000W |
6500W |
5500W*2—11KW |
|
MPPT Range@ Operating Voltage |
55-450VDC |
||||
|
Maximum PV Array Open Circuit Voltage |
450VDC |
||||
|
Maximum PV Input Current |
15A 15A 15A |
27A |
18A*2 |
||
|
Maximum Charging Current |
60A |
100A |
100A |
120A |
160A |
|
Maximum Efficiency |
99% |
||||
|
Parameter |
|
||||
|
Communication |
RS485 |
||||
|
IP level |
IP20 |
||||
|
Certificate |
CE |
||||
|
Operating Temperature |
-10℃to 55℃ |
||||
|
Storage Temperature |
-15℃ to 60℃ |
||||
|
Dimension. D*W*H(mm) |
358×295×100 |
358×295×100 |
358×295×100 |
450×300×130 |
537×390×130 |
|
Net Weight(kgs) |
6 |
6.5 |
7 |
9.6 |
15 |
|
Optional Configuration |
WIFI module |
||||
♦Independent Operation Capability: Off-grid Inverters Can Work Independently Without A Public Power Grid,Providing Power To Remote Areas Or Areas With Unstable Power Grids.
♦High Pv Input Voltage Range (55~450vdc)
♦Support Bms Communication With Lithium Batteries
